F type joining devices use for 75Ω cable assign system,especially CATV,broadcast television netword.It can already be used for having impedance to mate the occasion required,can be used in not mating the occasion too.It is joined,inserts helping jointly that its charac-teristic is whorl,the price is suitable.
F type joining devices can exchange and use with the similar products in the world.
- Temp.range : -40~+60°C
- Impedance : 75Ω
- Frequency range: 0~1GHz
- Center conductor withdrawal force ≥0.49N
- Contact resistance: center conductor ≤6mΩ , outer conductor ≤1mΩ
- Insulation resistance ≥ 1000 MΩ
- Withstand voltage at sea level : 750V
- Working voltage : 170V max
- VSWR : Straight ≤1.2 Angle≤1.3
- Durability : 500 cycles
- double male F quick connector adapter
- male to male F quick plug adapter
- F male to F male quick fit connector
- double male push on F connector
- F male to F male push on connector
- Quick Fit F Connector Push On Adaptor Satellite
- F type push on adaptor coax connector easy plug
- Quick Fit F Connector Male/Plug To Female Adapter - Push On RF Coaxial
- F-Quick Male PLUG Straight Coaxial TV adapter
