Description
- 1/2.8" 2MP PS CMOS Image Sensor (7.112 centimeters)
- Max 25/30fps@1080P
- Ultra H.265, H.265, H.264, MJPEG Triple-stream encoding
- WDR(120dB), Day/Night(ICR), Defog, Corridor mode, 3D-DNR, ROI, AWB, AGC, BLC, HLC
- 2.8~12mm Varifocal Lens
- IR Range of 30 Mtrs, Smart IR, Micro SD, IP67, IK10, PoE
- Supports Instastream technology, save diskspace and bandwidth upto 70%
- Mobile Software: Android, iOS
- CMS Software: IVMS
Specs
| Image Sensor | 1/2.8" 2MP PS CMOS Image Sensor (7.112 centimeters) |
| Minimum Illumination | Colour: 0.002Lux (F1.6, AGC ON) 0Lux with IR |
| BodyType | Vandal Dome |
| Shutter Speed | Auto/Manual, 1~1/100000 s |
| White Balance | Auto/Manual |
| Lens | 2.8~12mm Varifocal Lens |
| AGC Control | Auto/Manual |
| Video Compression | Ultra 265,H.265, H.264, MJPEG |
| Angle of View | 94.0° ~28.0° (H), 56.7° ~ 14.4°(V), 122.2° ~ 34.4°(O) |
| S/N Ratio | >52dB |
| Back Light Comp. | BLC/HLC/WDR(120dB) |
| Frame Rate | Main Stream: 2MP (1920×1080): Max. 30 fps; Sub Stream: 2MP (1920×1080): Max. 30 fps; Third Stream: D1 (720×576): Max. 30 fps |
| Video Streaming | Triple |
| Video Output | 1 BNC, impedance 75 O; amplitude 1 V [p-p] |
| Resolution | 1920 × 1080 |
| Motion Detection | Up to 4 areas |
| Privacy Mask | Up to 8 areas |
| ICR | IR-cut filter with auto switch (ICR) |
| ROI | Up to 8 areas |
| Audio Input | impedance 35 kO; amplitude 2 V [p-p] |
| OSD | Up to 8 OSDs |
| Audio Output | impedance 600 O; amplitude 2 V [p-p] |
| Audio | Two-way audio Supported |
| Alarm IN | 1 IN |
| Alarm Out | 1 Out |
| Protocol | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, SSL, TLS, ONVIF (Profile S, Profile G), API |
| Ethernet | 1 RJ45 10M/100M Base-TX Ethernet |
| IR Range | IR Range of 30 Mtr., Smart IR |
| Micro SD | Up to 256GB |
| Operating Temperature | -40°C ~ +60°C (-40°F ~ 140°F) |
| Power Source | DC12V±25%, PoE (IEEE802.3 af) |
| Humidity | <95% RH(non-condensing) |
| Power Consumption | max. 7.2 W |
| Weatherproof Standard | IP67 & IK10 |
| Dimension | Φ148 x 111.3 mm (Ø5.8” x 4.4”) |
| Weight | 0.75 kg |
